VX/AT Management Central Switch

Features

  • System on a chip technology
  • Supervises up to 512 amplifier modules
  • Interfaces to other life critical systems

Technical Data

Dimensions483 mm wide (19″), 44.5 mm high (1 unit), 160 mm deep
Weight1.4 kg
VoltagePower supply: DC 48 V
CurrentConsumption: 25 W
Power dissipationHeat emission:10 W
Frequency150 Hz to 7 kHz tailored to optimise speech intelligibility

*Refer to the documentation for more detailed information

Details

Ambient temperature

-20 °C to +50 °C
