VA 300-MON8 Audible Monitor Panel

Features

  • Small size compact 1U high design
  • Smaller and lighter overall central panels
  • Rapid service/maintenance minimises down time

Description

The MON-8 is a 1 Unit high 19-inch rack mount panel designed to allow the engineer to monitor program output from each of the VA300+M amplifiers fitted to a Vodec VA300/CAGE-M. The unit consists of a compact miniature loudspeaker, volume control and eight way selector (corresponding to eight amplifier slots in the VA300/CAGE-M). Connection to the VA300/MON-8 is by twisted pair ribbon (transports program output from each amplifier selected) which routes amplifier outputs from either:

  1. PAS88 or
  2. EOL03A or
  3. LTP series of amplifier loudspeaker termination ports.

The complete assembly eliminates conventional hard-wiring by the employment of a “motherboard” style construction utilising a multi-sided printed circuit board. Plug in/out connections enable rapid installation and maintenance supporting hot-swap capability.

Technical Data

Dimensions483.5 mm x 44.5 mm x 50 mm
(19.02 inch x 1.75 inch x 6.30 inch)
Weight1.0 kg (2.2 lbs)
VoltageNo separate power supply required.
Unit is driven by amplifier cage.

*Refer to the documentation for more detailed information

Details

Ambient temperature

0 °C to +50 °C (+32 °F to +122 °F)
